Saddle-Shaped Shade Structure
One of our most exciting designs, the Helena Modular Structure is a circular, anticlastic saddle-like structure.
Supported by three lightweight V-shaped columns at the perimeter, Helena is a bright, open and airy structure, perfect for shading and weather proofing a school courtyard or covered outdoor learning area.
The wave-like upper curve can be positioned over the top of adjacent buildings.
Helena is also a star performer for outdoor stages and other public and community shade projects.
CUSTOMISATION
- Helena has three lightweight V-shaped columns as standard, but can be engineered with Y-shaped columns.
- Rainwater sumps can be installed at the lower points, with downpipes painted to match the columns.
- Lighting and electrical connectivity available.
| MODEL NUMBER | APPROX. CANOPY AREA | CANOPY DIAMETER | STRUCTURE HEIGHT | UNDER CANOPY CLEARANCE |
|---|---|---|---|---|
| m2 | (D) mm | (H) mm | (C) mm | |
| HE110 | 98.5 | 11200 | 4300 | 2450 |
| HE140 | 158.4 | 14200 | 6630 | 4000 |
| HE160 | 206.2 | 16200 | 5100 | 2350 |
| Dimensions are a guide-only. | ||||
Anticlastic Curves
An anticlastic curved shape refers to a plane curved in opposite ways in two directions.
The most notable anticlastic forms are a Western-style saddle and a famous brand of snack food!
